Z bezpečnostných a záručných dôvodov si tento výrobok vyžaduje, aby ho inštalovala len osoba s príslušnou elektrotechnickou kvalifikáciou.
Technické údaje:
| menovité napätie | 230V~ |
| výkon | 1100W |
| dĺžka po prírubu | 370 mm |
| šírka | 315 mm |
| rozmer príruby | 20 x 105 mm |
| rozteč kontaktov | 60 mm |
| dĺžka kontaktov od príruby | 40 mm |
| Typ Mora, Gorenje (ART) | Typ Mora, Gorenje (ART) |
| 09 LLO (625950) | EC275W (153523) |
| 2603.0A12 (164953) | EC275W (179852) |
| 2604.0A32 (164952) | EC276W (102899) |
| 2605.0A12 (293088) | EC2770E (231767) |
| 2606.0A32 (293087) | EC2770E (695425) |
| 2651.0A32 (161912) | EC277B (695406) |
| 2651.1A32 (161913) | EC277E (695407) |
| 320BK (245921) | EC277W (695405) |
| 320SS (245910) | EC278E (153535) |
| 3603.0010 (133124) | EC278E-U (224845) |
| 3651.0010 (133303) | EC3000SM-W (169815) |
| 4670.0000 (131911) | EC300SM-E (169221) |
| 71255W (271634) | EC300SM-EK (290942) |
| 787BK (179348) | EC300SM-W (169809) |
| B1100W (225875) | EC3302E (705320) |
| B1-ORA-E (171361) | EC3302E-NO (113819) |
| B1-ORA-E (178352) | EC3302W-NO (100687) |
| B1-ORA-S (171362) | EC333E (287265) |
| B1-ORA-S (178353) | EC333W (187654) |
| B1-ORA-W (245928) | EC3402E (158171) |
| B2000P2 (125887) | EC3402W (155476) |
| B2000P2 (154026) | EC3402W (155476) |
| B2000P2 (158789) | EC4000SM-E (169816) |
| B2000P2 (286154) | EC400SM-EK (290942) |
| B2000P2 (297767) | EC433E (287265) |
| B2000P2 (304520) | EC433W (293061) |
| B2000P2B (188748) | EC444E (194901) |
| B2410E (196607) | EC444W (194900) |
| B2410E (222722) | EC52103AW (325383) |
| B2410E (228435) | EC52166AW (337286) |
| B2410W (196608) | EC52203AW (325404) |
| B2450E (155256) | EC52203AX (325393) |
| B2450W (156242) | EC52303ABR (325405) |
| B2470E (152349) | EC52303AW (325394) |
| B2475E (161205) | EC52303AX (325406) |
| B2475W (161206) | EC535B (266673) |
| B2-ORA-E (171363) | EC535W (266672) |
| B2-ORA-E (178354) | EC55101AW (330607) |
| B2-ORA-S (171364) | EC55110AX (379702) |
| B2-ORA-S (178355) | EC55121AX (379701) |
| B2-ORA-W (257314) | EC55220AW (325396) |
| B3200E (231305) | EC55220AX (373797) |
| B3320E (665942) | EC55320RBR (325407) |
| B3345E (168102) | EC55320RW (323550) |
| B3350E (197410) | EC55335AW (323559) |
| B3365AL (161210) | EC55335AW0 (325411) |
| B3365E (168101) | EC55335AX0 (325412) |
| B3365E (188613) | EC56103AW (354906) |
| B3365E (196609) | EC56103AX (354905) |
| B3400E (160738) | EC5705E (146806) |
| B3400E (189619) | EC57102AW (354904) |
| B3400W (160737) | EC57103AW (354903) |
| B3410E (147868) | EC57120AW (351610) |
| B3410E-1 (156197) | EC57120AX (351621) |
| B3410W-1 (197867) | EC57320AW (351622) |
| B3455E (226025) | EC57320AX (351623) |
| B3460E (172120) | EC57335AW (325402) |
| B3470E (147869) | EC57335AX (330924) |
| B3500E (179851) | EC57335AX (351626) |
| B3535CB (161214) | EC57341AW (323564) |
| B3535CS (161216) | EC57341AX (325403) |
| B3535CW (161215) | EC57345AW (325414) |
| B3560E (227535) | EC57345AX (323561) |
| B3570E (167177) | EC57366AW (337285) |
| B3575E (161220) | EC57366AX (337243) |
| B3575S (161219) | EC573E-1 (156147) |
| B3575W (161217) | EC573W (147996) |
| B3860E (168104) | EC573W-1 (156158) |
| B3960SG (161212) | EC574W (330607) |
| B4455E (130561) | EC576W (126047) |
| B4465E (168125) | EC5775E (695427) |
| B4470E (168122) | EC5775W (695426) |
| B4485E (168123) | EC5776E (153547) |
| B4490E (168120) | EC5776W (153542) |
| B50EP (705313) | EC577E-2 (156128) |
| B50EP-P2D (168538) | EC577W-1 (156144) |
| B50PP (705314) | EC578E (224987) |
| B7405B (162764) | EC578W (224986) |
| B7405E (162270) | K737E (266718) |
| B7405W (162273) | K737W (266717) |
| B7420E (168079) | K7702W (161834) |
| B7445E (166713) | K7703E (162267) |
| B7445W (166722) | K7703E (166021) |
| B7455E (166719) | K7703W (152225) |
| B7465E (161207) | K7703W (161878) |
| B7465E (226029) | K7704W (161928) |
| B7465S (161209) | K7705E (166020) |
| B7465W (161208) | K7705W (161930) |
| B7485E (168105) | K7706E (161931) |
| B7500E (188615) | K7706E (161940) |
| B7500E (196605) | K7706ET (161926) |
| B7500E (228439) | K7706W (161932) |
| B7500S (224680) | K7706W (161941) |
| B7500W (224694) | K7706WT (182592) |
| B7520E (179869) | K7708E (177612) |
| B7570E (196606) | K7708W (177611) |
| B7570E (228432) | K7709E (161948) |
| B7575E (161224) | K7710E (161949) |
| B7575E (188621) | K7710E (176693) |
| B7575S (161222) | K7710E (199415) |
| B7575W (161221) | K7710W (161950) |
| B7580E (140703) | K7712B (179860) |
| B7580E (153872) | K7712E (179861) |
| B7585S (152371) | K7712W (179855) |
| B7890E (168103) | K7713W (161873) |
| B7920E (191529) | K7720W (183227) |
| B7920W (191547) | K7722B (165607) |
| B7960E (191530) | K7722E (161842) |
| B7960W (191531) | K7722W (161843) |
| B8575AL (187652) | K7722W (179821) |
| B8950E (174790) | K7723B (161875) |
| B8955E (188609) | K7723E (161876) |
| B8960SG (161213) | K7723W (161877) |
| B8970E (140708) | K7723W (199416) |
| B8970E-P2D (168535) | K7726W (179820) |
| B8970W-P2D (168536) | K7728E (179812) |
| B8985E (161226) | K772BD (164867) |
| B8985E (169223) | K772ED (164864) |
| B8985S (161225) | K772WD (164861) |
| B8990AL (228438) | K773BD (164884) |
| B8990E (140705) | K773ED (164881) |
| B8990E (228431) | K773WD (164877) |
| B8990E-3P (168533) | K774W (164962) |
| B9000AL (665911) | K775E (164959) |
| B9000AL-1 (101256) | K775EM (168135) |
| B9000BK (154363) | K775W (164958) |
| B9000E (120806) | K775WM (168134) |
| B9000E (130816) | K7766E-2 (161942) |
| B9000E (665900) | K776B (164977) |
| B9000E-1 (156080) | K776E (164976) |
| B9000SG-1 (156285) | K776E (224985) |
| B9000W-1 (156081) | K776W (164975) |
| B9005E (155165) | K776W (224983) |
| B9010AL (140711) | K778B (224984) |
| B9010AL (154014) | K778E (224985) |
| B9010AL (228407) | K778E (261178) |
| B9010AL-3P (168280) | K778W (224983) |
| B9010E (140710) | K778W (261177) |
| B9010E (153597) | K779E (164969) |
| B9010E (154013) | K779W (164968) |
| B9010E (196604) | KN131W (164936) |
| B9010E (228437) | KN132W (164935) |
| B9010E-3P (168279) | KN2303W (178994) |
| B9015AL (163168) | KN2305W (161882) |
| B9019AL (152380) | KN2306W (178992) |
| B9019E (152381) | KN233W (178966) |
| B9050E (174791) | KN2703W (161849) |
| B9090AL (174799) | KN2703W (161856) |
| B9090E (173083) | KN272B (266705) |
| B9095E (179872) | KN272W (266704) |
| BC1100B (354236) | KN273W (164888) |
| BC1100W (354237) | KN273W (266706) |
| BC1100X (354235) | KN275W (164951) |
| BL2300IX (157042) | KN434E (164923) |
| BL2300W (157041) | KN474B (261176) |
| BL3300IX (157044) | KN474E (164902) |
| BL3300W (157043) | KN474E (308295) |
| BL3400IX (187673) | KN474W (164901) |
| BL5059IX (170714) | KN474W (261175) |
| BL5059W (170708) | KN474W-1 (164900) |
| BL5060BR (163167) | KN475E (162152) |
| BL5060IX (164950) | KN475E (164898) |
| BL5060W (164949) | KN475E (164899) |
| BL6055IX (163411) | KN475E-2 (164915) |
| BL6055IX (166025) | KN475W (162150) |
| BL6055W (163408) | KN475W (164896) |
| BL6055W (166024) | KN475W (164897) |
| BL6059BR (170706) | KN475W-1 (164914) |
| BL6059IX (163166) | KN476E (164895) |
| BL6059IX (166023) | KN476E-1 (164913) |
| BL6059W (163165) | KN476W (164894) |
| BL6059W (166022) | KN476W-1 (164912) |
| BL6060BR (161921) | KN477E (164974) |
| BL6060IX (161922) | KN477EM (168130) |
| BL6060W (161923) | KN477W (164973) |
| BL7390IX (196602) | KN477WM (168128) |
| BL7400IX (157046) | U1400E (140540) |
| BL7400W (157045) | U1400S (140499) |
| BLG5055IX (290863) | U1400W (140498) |
| BLG5055W (290862) | U2300E (135974) |
| BO1100X (354238) | U2410B (140545) |
| BO1100X (354238) | U2410E (140547) |
| BO990X (390120) | U2410W (140546) |
| C55220AX (373797) | U2470E (152348) |
| CG3000 (316304) | U2475E (161201) |
| CG3000K (316338) | U3300AL (665902) |
| CS681X (352246) | U3300E (655605) |
| E132W (147968) | U3400E (140544) |
| E134W (171595) | U3400E-1 (156198) |
| E135W (147969) | U3400W (140543) |
| E136W (147970) | U3400W-1 (156196) |
| E200SM-W (169807) | U3475E (152353) |
| E2304W (164069) | U3475E (161202) |
| E2304W (223355) | U3475S (152352) |
| E2305W (165598) | U3475W (152351) |
| E234W (171596) | U4300E (665917) |
| E234W (178967) | U4300W (665916) |
| E234W (625799) | U7360E (145362) |
| E235W (164054) | U7360W (145361) |
| E2703W (188772) | U7410B (140549) |
| E2704W (635689) | U7410E (140679) |
| E2705B (165599) | U7410S (140548) |
| E2705E (223081) | U7410W (140574) |
| E2705W (185263) | U7450E (665939) |
| E271B (195722) | U7460E (655621) |
| E271W-E (198856) | U7500B (160735) |
| E275B (165577) | U7500E (140684) |
| E434W (296223) | U7500E (153865) |
| E52102AW (325333) | U7500W (140683) |
| E52102AW1 (325381) | U7500W (160734) |
| E52166AW (337287) | U7540E (147879) |
| E52260AW (325382) | U7540W (147878) |
| E535W (266670) | U7570E (147890) |
| E540W (369284) | U7570E (161203) |
| E55220AW (373796) | U7575E (147892) |
| E55329AW (325332) | U7575W (147891) |
| E57120AW (372279) | U7580E (140685) |
| E57366AW (338164) | U7585AL (152359) |
| E640X (369289) | U7585E (152358) |
| E7304W (164070) | U7585S (152357) |
| E7304W (223357) | U7585W (152356) |
| E734W (164056) | U7860E (136487) |
| E737W (316304) | U8985E (163688) |
| E7705W (148005) | U8990AL (140689) |
| E7705W (165605) | U8990E (140688) |
| E775W (147980) | U8990E (152374) |
| E775W (165585) | U8990E (154016) |
| E7775W (153302) | U8990E (161204) |
| E778W (153301) | VT20.0000 (168081) |
| E91303W-NO (179862) | VT21.0000 (173026) |
| E9235W-NO (179863) | VT21.1000 (173037) |
| E9238W-NO (227540) | VT25.0000 (196610) |
| EB654E (168319) | VT401EX (333671) |
| VT402EX (333676) |
| VT422EX (333674) |
| VT526EX (333733) |
| VT566EX (333720) |
| VT568EX (333719) |
| ZT02.0000 (138697) |
| ZT02.1020 (138695) |
| ZT06.1020 (138698) |
| ZT14.0000 (138694) |
| ZT14.1020 (138693) |
| ZT16.0000 (138701) |
| ZT16.1020 (138700) |
